GP-GSTFS31480GNTD
-
InterfaceSATA 6.0Gb/s
-
Form Factor2.5-inch internal SSD
-
Total Capacity480GB
-
NANDNAND Flash
-
External DDR CacheN/A
-
Sequential Read speedUp to 550 MB/s
-
Sequential Write speedUp to 480 MB/s
-
Random Read IOPSup to 75k
-
Random Write IOPSup to 70k
-
Dimension69.85 x 7 x 100 mm
-
Mean time between failure (MTBF)2M hours
-
Power Consumption (Active)Average: R : 2240mW; W : 2610mW
-
Power Consumption (Idle)170mW
-
Temperature (Operating)0°C to 70°C
-
Temperature (Storage)-40°C to 85°C
-
Warranty
- 1. Limited 3-years or 200TBW
- 2. Limited warranty based on 3 years or 200TBW, whichever comes first.
*TBW (Terabyte Written):Terabytes Written is the total amount of data that can be written into an SSD before it is likely to fail. - 3. The “percentage of SSD life” (SMART ID: E7 or A9) in SMART page of the “GIGABYTE SSD toolbox” program will be used as the determining criteria when the number is 0 means out of warranty. (A new unused product will show the percentage of 100.)
-
Note
- • Test system configuration: configuration may vary by models; we will choose the latest platform for verification.
- • Performance may vary based on SSD’s firmware version and system hardware & configuration. Sequential performance measurements based on CrystalDiskMark and IOmeter 1.1.0.
- • Speeds based on internal testing. Actual performance may vary.
- • 1GB = 1 billion bytes. Actual useable capacity may vary.
